Fixing CMSIS DAP V1 Initialization Issues on Windows

If you're encountering issues initializing your CMSIS DAP V1 probe on Windows, you're not alone! This article dives into a common problem reported by developers using pyOCD with USB Low Speed CMSIS DAP V1 probes and offers potential solutions. We'll break down the error, explore the underlying causes, and provide steps you can take to get your probe up and running.

Understanding the "RuntimeError: already open" Error

The core issue we're tackling is the RuntimeError: already open that arises during probe initialization with pyOCD on Windows. This error typically manifests as a traceback similar to the one below:

Traceback (most recent call last):
  File "pyocd\__main__.py", line 161, in run
    status = cmd.invoke()
  File "pyocd\subcommands\commander_cmd.py", line 75, in invoke
    PyOCDCommander(self._args, cmds).run()
  File "pyocd\commands\commander.py", line 83, in run
    if do_connect and not self.connect():
  File "pyocd\commands\commander.py", line 224, in connect
    if not self._post_connect():
  File "pyocd\commands\commander.py", line 251, in _post_connect
    self.session.open(init_board=not self.args.no_init)
  File "pyocd\core\session.py", line 549, in open
    self._probe.open()
  File "pyocd\probe\shared_probe_proxy.py", line 55, in open
    self._probe.open()
  File "pyocd\probe\cmsis_dap_probe.py", line 277, in open
    self._link.open()
  File "pyocd\utility\concurrency.py", line 29, in _locking
    return func(self, *args, **kwargs)
  File "pyocd\probe\pydapaccess\dap_access_cmsis_dap.py", line 752, in open
    self._interface.open()
  File "pyocd\probe\pydapaccess\interface\hidapi_backend.py", line 144, in open
    self.device.open_path(self.device_info['path'])
  File "hid.pyx", line 155, in hid.device.open_path
RuntimeError: already open

This traceback indicates that the program is attempting to open a device (the CMSIS DAP probe) that is already considered open by the system. This can occur due to various reasons, including improper resource handling within pyOCD or the underlying HIDAPI library, or even conflicts with other software accessing the probe.

Why does this happen, guys? Several factors could be at play here. One potential cause is an error occurring during the initial connection attempt, such as the "DAP_Info Packet Size exceeds endpoint wMaxPacketSize" warning. While this warning might not seem fatal, it could be disrupting the proper initialization sequence, leaving the probe in a state where it's perceived as open without being fully initialized. Another possibility is that a previous pyOCD session didn't properly close the connection to the probe, leaving it in a locked state. It's like when you try to open a file on your computer that's already open in another program – Windows throws a fit!

Diving Deeper into Potential Causes

To effectively troubleshoot this issue, let's explore the common culprits in detail:

Resource Contention: Another application might be holding a lock on the CMSIS-DAP probe. This is akin to two programs trying to access the same file simultaneously. Debugging tools, other pyOCD instances, or even background processes could be the contenders.
Incomplete Closure: If a prior pyOCD session terminated abnormally (e.g., crashed or was forcefully closed), it might not have released the probe handle properly. This can leave the device in a zombie-like state, where it's technically open but unresponsive.
HIDAPI Glitches: The HIDAPI library, which pyOCD uses for low-level communication with USB HID devices, might have platform-specific quirks or bugs. Issues within HIDAPI itself could lead to incorrect device state tracking.
Packet Size Mismatch: The "DAP_Info Packet Size exceeds endpoint wMaxPacketSize" warning points to a potential incompatibility between the probe's configuration and the host's expectations. Although seemingly a warning, this discrepancy might trigger errors in the initialization process on some systems.
Driver Issues: While less common, outdated or corrupted USB drivers can cause unpredictable behavior. If the drivers for your CMSIS-DAP probe are acting up, it's like trying to drive a car with flat tires – things just won't work smoothly.

Troubleshooting Steps to Resolve the Issue

Now that we understand the potential causes, let's walk through practical steps you can take to resolve the RuntimeError: already open error.

1. Check for Other Processes Using the Probe

First and foremost, ensure that no other applications are actively using the CMSIS DAP probe. This is the most common cause and the easiest to fix. Close any other debugging tools, IDEs, or programs that might be accessing the probe. Also, terminate any other running instances of pyOCD. You can use Task Manager (Ctrl+Shift+Esc) on Windows to check for and close any rogue processes. Think of it as clearing the stage so that pyOCD has exclusive access to the spotlight!

2. Disconnect and Reconnect the Probe

Sometimes, a simple disconnection and reconnection can work wonders. Unplug the USB cable from your computer, wait a few seconds, and then plug it back in. This can reset the device's state and clear any lingering locks. It's like giving the probe a quick power nap to refresh its memory.

3. Restart Your Computer

If a disconnect/reconnect doesn't do the trick, try restarting your computer. This ensures that any lingering processes or resources that might be holding onto the probe are cleared. A full reboot can be a surprisingly effective solution, like hitting the reset button on the entire system.

4. Update pyOCD

Make sure you're running the latest version of pyOCD. Newer versions often include bug fixes and improvements that can address compatibility issues. You can update pyOCD using pip:

pip install -U pyocd

Keeping pyOCD up-to-date is like making sure you have the latest software patches on your phone – it helps keep things running smoothly and securely.

5. Investigate Driver Issues

Outdated or corrupted USB drivers can also cause problems. Try updating the drivers for your CMSIS DAP probe. You can usually do this through Device Manager on Windows. Look for your probe under the "Ports (COM & LPT)" or "Universal Serial Bus devices" section. Right-click on the device and select "Update driver". It's like giving your car a tune-up to ensure everything is running efficiently.

6. Address the Packet Size Warning

While the "DAP_Info Packet Size exceeds endpoint wMaxPacketSize" warning might not be the direct cause of the RuntimeError, it's worth investigating. This warning indicates a potential mismatch between the probe's expected packet size and the USB endpoint's maximum packet size. While the author of the original query mentioned this doesn't happen on macOS, it seems to be a Windows specific problem. Some possible resolutions are:

Lower probe speed: Trying to lower the probe speed in the pyOCD configuration might help mitigate issues related to packet size limitations. It's like slowing down the data flow to ensure everything gets transmitted correctly.
Firmware Update: Check if there's a firmware update available for your CMSIS DAP probe. A firmware update might address the packet size issue or improve overall compatibility. It's like giving your device a brain upgrade to handle new challenges.
Check your USB connection: Sometimes the issue can be caused by a physical connection problem or USB hub that has speed limitations. Connecting the probe directly to a USB port on your computer (avoiding hubs) and/or trying a different USB port can sometimes help.

7. Create a Clean pyOCD Environment

In some cases, conflicts with other Python packages or libraries can interfere with pyOCD's operation. Creating a virtual environment for pyOCD can isolate its dependencies and prevent such conflicts. Here's how to create a virtual environment:

python -m venv .venv

Activate the virtual environment:

Windows: .venv\Scripts\activate
macOS/Linux: source .venv/bin/activate

Then, install pyOCD within the virtual environment:

pip install pyocd

Using a virtual environment is like having a dedicated workspace for your project, preventing accidental spills from other projects.

8. Check HIDAPI Backend

If you suspect HIDAPI might be the culprit, try using a different HIDAPI backend within pyOCD, if available. PyOCD may offer different backend implementations for HID communication, and switching to an alternative might bypass any issues specific to the current backend. You can look into pyOCD documentation on how to configure this, as it may involve modifying the pyOCD configuration file or using command-line arguments.

9. Debug with Verbose Logging

When all else fails, verbose logging can provide valuable clues. Use the -vvvvv flag with pyOCD commands to enable maximum logging output. This will generate a detailed log of pyOCD's activities, which might reveal the exact point where the RuntimeError occurs and the underlying reason. Share this log with the pyOCD community or support channels for further assistance. Think of verbose logging as a black box recorder for your debugging session.

The Importance of Community and Support

If you've exhausted these troubleshooting steps and are still facing the RuntimeError: already open issue, don't hesitate to seek help from the pyOCD community or other relevant support channels. Online forums, mailing lists, and issue trackers are excellent resources for connecting with experienced users and developers who can offer guidance and insights. Remember, you're not alone in this! Sharing your experiences and error logs can help others facing similar challenges and contribute to the overall improvement of pyOCD.

Conclusion

The RuntimeError: already open error during CMSIS DAP V1 probe initialization on Windows can be frustrating, but by systematically working through the troubleshooting steps outlined in this article, you can increase your chances of resolving the issue. Remember to check for conflicting processes, ensure proper driver installation, address packet size warnings, and leverage the power of community support. With persistence and a methodical approach, you'll be back to debugging and developing in no time!
