This article delves into a discussion regarding the appropriate image pad value within the pi0/pi05 context, specifically concerning the resize_with_pad_torch function in the LeRobot framework. We'll explore the nuances of this function, examine the expected behavior, and address a potential issue related to the constant padding value.

System Information

This discussion pertains to the latest version of LeRobot. It's crucial to ensure you're working with the most up-to-date version to benefit from the latest fixes and features. Keeping your system current is a foundational step in troubleshooting and optimizing performance.

Background

The core of this discussion revolves around the resize_with_pad_torch function. This function, directly derived from the openpi library, plays a crucial role in image preprocessing within LeRobot. It intelligently resizes images to a specified target height and width while maintaining their aspect ratio. This is achieved by padding the images with a constant value, typically black, to fill the extra space. The function is designed to handle both channels-last ([*b, h, w, c]) and channels-first ([*b, c, h, w]) image formats, adding to its versatility.

Understanding resize_with_pad_torch

The resize_with_pad_torch function in LeRobot, adapted from the openpi library, is a powerful tool for image preprocessing. Let's break down its functionality step by step:

def resize_with_pad_torch(
    images: torch.Tensor,
    height: int,
    width: int,
    mode: str = "bilinear",
) -> torch.Tensor:
    """PyTorch version of resize_with_pad. Resizes an image to a target height and width without distortion
    by padding with black. If the image is float32, it must be in the range [-1, 1].

    Args:
        images: Tensor of shape [*b, h, w, c] or [*b, c, h, w]
        height: Target height
        width: Target width
        mode: Interpolation mode ('bilinear', 'nearest', etc.)

    Returns:
        Resized and padded tensor with same shape format as input
    """
    # Check if input is in channels-last format [*b, h, w, c] or channels-first [*b, c, h, w]
    if images.shape[-1] <= 4:  # Assume channels-last format
        channels_last = True
        if images.dim() == 3:
            images = images.unsqueeze(0)  # Add batch dimension
        images = images.permute(0, 3, 1, 2)  # [b, h, w, c] -> [b, c, h, w]
    else:
        channels_last = False
        if images.dim() == 3:
            images = images.unsqueeze(0)  # Add batch dimension

    batch_size, channels, cur_height, cur_width = images.shape

    # Calculate resize ratio
    ratio = max(cur_width / width, cur_height / height)
    resized_height = int(cur_height / ratio)
    resized_width = int(cur_width / ratio)

    # Resize
    resized_images = F.interpolate(
        images,
        size=(resized_height, resized_width),
        mode=mode,
        align_corners=False if mode == "bilinear" else None,
    )

    # Handle dtype-specific clipping
    if images.dtype == torch.uint8:
        resized_images = torch.round(resized_images).clamp(0, 255).to(torch.uint8)
    elif images.dtype == torch.float32:
        resized_images = resized_images.clamp(-1.0, 1.0)
    else:
        raise ValueError(f"Unsupported image dtype: {images.dtype}")

    # Calculate padding
    pad_h0, remainder_h = divmod(height - resized_height, 2)
    pad_h1 = pad_h0 + remainder_h
    pad_w0, remainder_w = divmod(width - resized_width, 2)
    pad_w1 = pad_w0 + remainder_w

    # Pad
    constant_value = 0 if images.dtype == torch.uint8 else -1.0
    padded_images = F.pad(
        resized_images,
        (pad_w0, pad_w1, pad_h0, pad_h1),  # left, right, top, bottom
        mode="constant",
        value=constant_value,
    )

    # Convert back to original format if needed
    if channels_last:
        padded_images = padded_images.permute(0, 2, 3, 1)  # [b, c, h, w] -> [b, h, w, c]

    return padded_images
  1. Input Handling: The function accepts a PyTorch tensor representing the image(s), along with the desired height and width. It intelligently determines the image format (channels-last or channels-first) and adds a batch dimension if necessary.
  2. Resizing: The core of the function involves calculating the resize ratio to maintain the aspect ratio. It then uses F.interpolate to resize the image(s) to the calculated dimensions using the specified interpolation mode (defaulting to bilinear). The **interpolation mode** ensures that the image is scaled smoothly, minimizing distortion.
  3. Data Type Handling: The function meticulously handles different image data types. For torch.uint8 images, it rounds the resized images and clamps the values between 0 and 255. For torch.float32 images, it clamps the values between -1.0 and 1.0. This data type-specific clamping is crucial for maintaining image integrity and preventing unexpected behavior.
  4. Padding Calculation: The function calculates the padding required on each side (top, bottom, left, right) to achieve the target height and width. The divmod function is used to distribute the padding evenly.
  5. Padding Application: This is where the core issue lies. The function uses F.pad to apply the padding. The constant_value is set to 0 for torch.uint8 images and -1.0 for torch.float32 images. This is where the potential problem arises, as we'll discuss later.
  6. Format Conversion: Finally, the function converts the image back to the original format (channels-last or channels-first) if necessary and returns the padded image tensor.

The Expected Behavior and the Potential Issue

LeRobot's images typically have a pixel range of 0 to 1 and a data type of float32. Given this context, the resize_with_pad_torch function sets the constant_value to -1.0 for padding. This is intended to pad the image with black pixels within the normalized range. However, the concern arises when these padded images are fed into subsequent processing steps, specifically the siglip embedding.

The issue is that a pixel value of -1 in this context might not be the intended representation of a padded area. If the siglip embedding or other downstream processes interpret this -1 value in a way that negatively impacts the results, it could lead to inaccurate or undesirable outcomes. This is because -1 * 2 - 1 = -3, which might introduce unexpected artifacts or distortions in the embedding space.

The key question is: Is -1 the correct padding value for images that will be processed by siglip embedding, given that the input range is [0, 1]?

Diving Deeper into the Problem

To fully grasp the potential impact, let's consider the typical workflow where resize_with_pad_torch is used:

  1. Image Loading and Preprocessing: Images are loaded and potentially preprocessed to a range of [0, 1].
  2. Resizing and Padding: resize_with_pad_torch is applied to resize the images while maintaining the aspect ratio, padding with -1 where necessary.
  3. Embedding Generation: The padded images are fed into a model, such as siglip, to generate embeddings.
  4. Downstream Tasks: The generated embeddings are used for tasks like image classification, retrieval, or other analyses.

The potential problem lies in step 3. If the siglip model or its associated layers are not designed to handle negative pixel values, the -1 padding could introduce unforeseen issues. For example, the model might learn to associate -1 with specific features or patterns, leading to biased embeddings. Furthermore, if there are normalization layers in the model, like BatchNorm, this might lead to unexpected behavior, because the padding value would skew the mean and variance calculation of batch normalization.

Potential Solutions and Recommendations

To mitigate this potential issue, several solutions can be considered:

  1. Adjust the Padding Value: The most straightforward solution is to modify the resize_with_pad_torch function to use a padding value that is more appropriate for the siglip model. A value of 0 might be a better choice, as it represents black within the [0, 1] range and is less likely to cause issues with downstream processing.
  2. Normalization Adjustments: If using a padding value of 0 isn't feasible, one might consider adjusting the normalization scheme before feeding the images into the model. This can involve rescaling the image data to a different range or employing techniques like zero-center normalization.
  3. Model-Specific Considerations: It's crucial to thoroughly understand the siglip model's architecture and how it handles input values. Consulting the model's documentation or source code can provide valuable insights.
  4. Empirical Evaluation: The most reliable approach is to empirically evaluate the impact of different padding values on the final results. Train and test the model with various padding strategies and compare the performance metrics. This will help determine the optimal padding approach for the specific task.

Conclusion

The discussion surrounding the image pad value in pi0/pi05 highlights the importance of understanding the interplay between different image processing steps and their potential impact on downstream tasks. While the resize_with_pad_torch function provides a convenient way to resize and pad images, it's crucial to carefully consider the implications of the chosen padding value, especially when dealing with models like siglip. By understanding the potential issues and exploring the suggested solutions, we can ensure the integrity and accuracy of our image processing pipelines within LeRobot.

This detailed analysis encourages a deeper understanding of the function's inner workings and the potential ramifications of seemingly minor implementation details. It emphasizes the necessity for a holistic approach, considering all elements of the image processing pipeline to achieve optimal results. Remember, the devil is often in the details, and a thorough comprehension of these details is vital for the development of robust and reliable image processing systems.
